Q: Are you factory or a trading company? A: We are factory and a professional manufacture of concrete batching plant and cement silos. Q: What's your advantage? A: We are a young and active thinking group, we can design and also can advise special design according the clients detail requirements. Q: How about your producr quality? A: We are a factory that only do export, we must keep the high quality product to reduce the after-sale service cost. Q: Do you supply training and after-sale service? A: Yes,we will supply installation and training on site and also we have a professional service team that can solve all the problems as fast as possible. Q: How about your price? A: We will promise that you will get what you pay. Q: Do you have CE certificate for your concrete batching plant / cement silo? A: Yes, we have. Both are our patent products, certificated by CE.
|
Technical Parameter
|
||||||||||||
|
Model
|
JS 750
|
JS 1250
|
JS 1500
|
JS 2000
|
JS 3000
|
JS 4000
|
||||||
|
Charging capacity(L)
|
1200
|
2000
|
2400
|
3200
|
4800
|
6400
|
||||||
|
Discharging capacity(L)
|
750
|
1250
|
1500
|
2000
|
3000
|
4000
|
||||||
|
Production capacity(m3/h)
|
42
|
75
|
90
|
120
|
180
|
240
|
||||||
|
Mixing axle rotation speed(r/min)
|
29.9
|
29.67
|
26.75
|
23.5
|
23.4
|
22.85
|
||||||
|
Mixer motor power(kw)
|
2*15
|
2*22
|
2*30
|
2*37
|
2*55
|
2*75
|
||||||
|
Librication oil pump
motor power(kw)
|
0.09
|
0.09
|
0.09
|
0.09
|
0.09
|
0.09
|
||||||
|
Hydraulic system
motor power(kw)
|
2.2
|
2.2
|
2.2
|
2.2
|
2.2
|
2.2
|
||||||
|
Electromagnetism valve
power supply(V)
|
DC24
|
DC24
|
DC24
|
DC24
|
DC24
|
DC24
|
||||||
|
Mixing time(s)
|
<=40
|
<=40
|
<=40
|
<=40
|
<=45
|
<=45
|
||||||
|
No. of mixing arm
|
12
|
12
|
16
|
16
|
18
|
22
|
||||||
|
Max diameter of
aggregate(Detritus/
Pebble)
|
60/80
|
60/80
|
60/80
|
80/120
|
100/150
|
100/150
|
||||||
|
External dimensions(LxWxH)
|
2900x
2650x
2100
|
3000x
2750x
2100
|
2900x
3000x
2150
|
3450x
3000x
2150
|
3900x
3300x
2230
|
4500x
3310x
2230
|
||||||
|
Transportation dimensions(LxWxH)
|
2900x
2100x
2100
|
3000x
2100x
2100
|
2900x
2320x
2150
|
3450x
2320x
2250
|
3900x
2600x
2230
|
4500x
2600x
2230
|
||||||
|
Entire machine weight(kg)
|
5000
|
5300
|
6500
|
7500
|
9300
|
11800
|
||||||
JS Series Twin-Shaft Concrete Mixer integrates global advanced technologies, delivering proven reliability for critical infrastructure projects. Engineered for high-speed railways, expressways, hydro-power stations, and commercial concrete plants, it sets industry benchmarks through: Core Advantages 1. High Efficiency & Uniformity: 20-30s mixing cycle, homogeneity ≥95%. 2. Patented Seals: Triple-lip design extends service life by 3X vs conventional seals. 3. Premium Reducers: Opt for imported gearboxes (Sew/Eurodrive) or high-torque domestic units. 4. Auto-Lubrication System: Centralized grease supply protects shaft seals 24/7. 5. Safety Lock: Power-cut interlock prevents accidental startup during maintenance.
