JS1250 Twin Shaft Horizontal Concrete Mixing Equipment Concrete Mixer for Concrete Batching Plant

HK$12,000.00

Model Number: JS1250

JS1250

Discharging Capacity: 4.5m³

4.5m³
1000L
3m³
2.5M³
5m³
750L
500L
3.5M³
4m³
1.2M³
2M³
1.5M³
Model Number: JS1250
Discharging Capacity: 4.5m³, 1000L, 3m³, 2.5M³, 5m³, 750L, 500L, 3.5M³, 4m³, 1.2M³, 2M³, 1.5M³
Availability: In Stock Pre order Out of stock
Categories: Twin shaft concrete mixers
Description
twin shaft concrete mixer
JS Series Standard Twin-shaft Concrete Mixer,inspired by advanced technologies from home and abroad.Ever since it was sold into the market,its stable performance and excellent quality have quickly won the trust of majority of users.Now it has become our star products.It is mainly used in the mixing plants of high speed railways,expressways,airports, hydro-power stations,commercial concrete and so on.
Advantages of JS series Twin Shafts Mixer
1. High mixing efficiency, good uniformity;
2. The use of new patented sealing technology, sealing effect, long service life;
3. The use of advanced imported reducer or high reliability reducer (optional);
4. The top automatic lubrication pump, centralized lubrication, to ensure that the shaft seal more durable;
5. Power "security lock" design, from the respect for life;
6. Exquisite manufacturing process.
Technical Parameter
Model
JS 750
JS 1250
JS 1500
JS 2000
JS 3000
JS 4000
Charging capacity(L)
1200
2000
2400
3200
4800
6400
Discharging capacity(L)
750
1250
1500
2000
3000
4000
Production capacity(m3/h)
42
75
90
120
180
240
Mixing axle rotation speed(r/min)
29.9
29.67
26.75
23.5
23.4
22.85
Mixer motor power(kw)
2*15
2*22
2*30
2*37
2*55
2*75
Librication oil pump
motor power(kw)
0.09
0.09
0.09
0.09
0.09
0.09
Hydraulic system
motor power(kw)
2.2
2.2
2.2
2.2
2.2
2.2
Electromagnetism valve
power supply(V)
DC24
DC24
DC24
DC24
DC24
DC24
Mixing time(s)
<=40
<=40
<=40
<=40
<=45
<=45
No. of mixing arm
12
12
16
16
18
22
Max diameter of
aggregate(Detritus/
Pebble)
60/80
60/80
60/80
80/120
100/150
100/150
External dimensions(LxWxH)
2900x
2650x
2100
3000x
2750x
2100
2900x
3000x
2150
3450x
3000x
2150
3900x
3300x
2230
4500x
3310x
2230
Transportation dimensions(LxWxH)
2900x
2100x
2100
3000x
2100x
2100
2900x
2320x
2150
3450x
2320x
2250
3900x
2600x
2230
4500x
2600x
2230
Entire machine weight(kg)
5000
5300
6500
7500
9300
11800
FAQ
Q: Are you factory or a trading company? A: We are factory and a professional manufacture of concrete batching plant and cement silos. Q: What's your advantage? A: We are a young and active thinking group, we can design and also can advise special design according the clients detail requirements. Q: How about your producr quality? A: We are a factory that only do export, we must keep the high quality product to reduce the after-sale service cost. Q: Do you supply training and after-sale service? A: Yes,we will supply installation and training on site and also we have a professional service team that can solve all the problems as fast as possible. Q: How about your price? A: We will promise that you will get what you pay. Q: Do you have CE certificate for your concrete batching plant / cement silo? A: Yes, we have. Both are our patent products, certificated by CE.
