Description





























































Offset pavers are used to produce monolithic concrete profiles such as protective concrete walls, kerb profiles, gutters or narrow paths. Thanks to numerous options, such as for concrete feeding or slipforming, offset slipform pavers are extremely versatile.
Multi-functional slipform pavers is a multi-purpose cement concrete construction equipment independently developed by our company. It is multi-purpose and can realize various mold configuration methods. It is widely used in road drainage ditches, drainage channels, curbs, shoulder stones, concrete guardrail cement concrete structures, farmland water conservancy channels and other construction fields. It replaces the traditional process and significantly improves the construction quality and speed of cement concrete structures. With slipform pavers, the concrete is placed directly in front of the machine and distributed by a spreading auger or spreading plough. Vibrators compact the concrete homogeneously and the mold forms it in the specified width and thickness as the slipform paver advances.

























































Basic Info.
           Model NO.



           NC600



           Type



           Paver



           Object



           Cement Concrete Pavement



           Product Capacity



           40~400t/h



           Certification



           ISO9001: 2000, CE



           Condition



           New



           Maximum Side Bunk Heiah



           600mm



           Paving Speed



           0-15m/Min



           Driving Speed



           0-22m/Min



           Engine Powere



           36.8kw



           Minimum Turning Radius



           3500mm



           Auger Speed



           0-60r/Min



           Track Size (Lxwxh)



           1340mmx300mmx514mm



           Specification



           4200x2500x2100



           Trademark



           HAMAC



           Origin



           China



           HS Code



           8479102100



           Production Capacity



           20 Pieces/Month


        Product Description


       Offset pavers are used to produce monolithic concrete profiles such as protective concrete walls, kerb profiles, gutters or narrow paths. Thanks to numerous options, such as for concrete feeding or slipforming, offset slipform pavers are extremely versatile.
Multi-functional slipform pavers is a multi-purpose cement concrete construction equipment independently developed by our company. It is multi-purpose and can realize various mold configuration methods. It is widely used in road drainage ditches, drainage channels, curbs, shoulder stones, concrete guardrail cement concrete structures, farmland water conservancy channels and other construction fields. It replaces the traditional process and significantly improves the construction quality and speed of cement concrete structures. With slipform pavers, the concrete is placed directly in front of the machine and distributed by a spreading auger or spreading plough. Vibrators compact the concrete homogeneously and the mold forms it in the specified width and thickness as the slipform paver advances.









       | NC600 | ||
| PROJECTI | UNIT | PARAMETER |
| Maximum side bunk heiah | m m | 600 |
| Maximum paving width | mm | 600 |
| Paving speed | m/min | 0-15 |
| Driving speed | m/min | 0-22 |
| Engine modele | / | (customizable)YCF3050-T302 |
| Engine powere | kw | 36.8 |
| Minimum turning radius | mm | 3500 |
| Outrigger hydraulic lifting stroke | mm | 430 |
| Auger speed | r/min | 0-60 |
| Auger conveying device dimensions | mm | 1600 |
| Vibrator interface | piece | 2 |
| Vibrator frequency | hz | 0-200 |
| Diesel tank | L | 100 |
| Hydraulic tank | L | 100 |
| Water tank | L | 158 |
| Track size (LxWxH) | MM | 1340x300x514 |
| Shipping dimensions (LxWxH) | MM | 4200x2500x2100 |
| Weight (unladen) | KG | 3200 |
