2018 Hot portable diesel concrete drum mixer JZR350DH
INTRODUCTION
PERFORMANCE
1. Diesel engine, especially suitable for the areas that without electricity.
2. Can be easily moved between different construction sites.
3. Easy operation; stable performance; Low energy consumption.
4. Reasonable structure, higher reliability, mixing evenly with high productivity.
MANUFACTURING PROCESS
SPECIFICATION
Model |
JZR350DH |
Discharging Capacity |
350 L |
Loading Capacity |
560 L |
Productivity |
10-14 m3/h |
Maximum Size of Aggregate |
60 mm |
Diesel Engine Power |
13.2KW |
Power of Water Pump |
0.75 KW |
Displacement of Gear Pump |
25 mL/r |
Pressure of Reversing Value |
16 Mpa |
Accuracy of Water Supply |
Error≤2 percentage |
Max Trailing Speed |
20 km/h |
Tyre Size |
6.50-16 |
Speed of Mixing Drum |
14 RPM |
Dimensions in Container (L×W×H) |
2300×1900×2500 mm |
Overall Weight |
1350 KGS |
